Siemens Simatic series User Manual

Device maintenance and repair
7.5 Installing the software
SIMATIC IPC547G
134 Operating Instructions, 04/2020, A5E49948632-AA
find information on how the data medium is partitioned in its factory state in the next
section.
2. Select the partition on which you want to install the operating system.
3. Click "Next".
Installation is started. The Windows operating system is installed on the data medium.
Information for systems with RAID or AHCI controller
Data carrier controllers unknown to the operating system must be made known to the
operating system prior to installation in the "Install Windows" installation program.
Requirement
You have copied the relevant controller driver to a USB stick.
Procedure
1. Connect the USB stick with the controller driver to the device.
2. Start the "Install Windows" installation program as described above.
3. Select "Load Drivers" in the Windows installation window.
4. Select the respective driver on the USB stick.
7.5.5 Partitions in the factory state
Partitions in the delivery state of Windows 7 and Windows Server 2008 R2
The following information applies to data storage media ≥ 200 GB.
Partition
Name
Size
File system
First Boot 260 MB FAT32, automatically set up by instal-
lation program
Second MSR 128 MB None, automatically set up by installa-
tion program
Third
System
160 GB
NTFS, not compressed
Fourth
Data
Remainder
NTFS, not compressed
Partitions in the factory state for Windows 7 Ultimate, 32-bit, MUI
The following information applies to data storage media ≥ 200 GB (MBR formatted).
Partition
Name
Size
File system
First BOOT 100 MB Automatically set up by installation
program
Second
SYSTEM
160 GB
NTFS not compressed
Third
DATA
Remainder
NTFS not compressed
