Technical specifications
8.4 Technical specifications
SIMATIC IPC547G
Operating Instructions, 04/2020, A5E49948632-AA
151
Electromagnetic compatibility
Emitted interference (AC) EN 61000-6-3; EN 61000-6-4;
CISPR 22, EN 55022 Class B; FCC Class A /
EN 61000-3-2 class D, EN 61000-3-3
Noise immunity:
interference conducted on the
power supply lines
± 2 kV; according to IEC 61000-4-4; burst
± 1 kV; according to IEC 61000-4-5; surge symm
± 2 kV; according to IEC 61000-4-5; surge symm
Noise immunity on signal lines ± 2 kV; according to IEC 61000-4-4; burst; length > 30 m
± 1 kV; according to IEC 61000-4-4; burst; length < 30 m
± 2 kV; according to IEC 61000-4-5; burst; length > 30 m
Immunity to discharges of static
electricity
± 4 kV contact discharge (according to IEC 61000-4-2)
± 8 kV air discharge; (according to IEC 61000-4-2)
Immunity to RF interference
• 10 V/m; 80 up to 1000 MHz
80% AM to IEC 61000-4-3
• 3 V/m; 1.4 to 2 GHz
80% AM to IEC 61000-4-3
• 1 V/m; 2 up to 2.7 GHz
80% AM to IEC 61000-4-3
• 10 V; 150 kHz up to 80 MHz
30 A/m; 50 Hz; 60 Hz (according to IEC 61000-4-8)
Ambient conditions
Climatic ambient conditions
Tested according to IEC 60068-2-2; IEC 60068-2-1; IEC 60068-2-14
Operation +0 °C up to +40 °C
1
Gradient: ≤ 10 K/h; no condensation
Storage/transportation –20 °C up to +60 °C
Gradient: ≤ 20 K/h; no condensation
Tested according to IEC 60068-2-78; IEC 60068-2-30
0 to 31 °C: 5-85 %; decreasing linearly to 5-50 % at 40° C
Storage/transportation 5% up to 95% at 25 °C to 55 °C; no condensation
Gradient: ≤ 20 K/h; no condensation
Operation 1080 up to 689 hPa,
corresponds to an altitude of –1000 m to 3000 m
Storage/transportation 1080 up to 660 hPa,
Corresponds to an altitude of -1000 m to 3500 m
Mechanical ambient conditions
Tested according to IEC 60068-2-6; 10 cycles
