07.97 12 Functional Descriptions
12.32.14 Example on a double-slide turning machine
• Protection zone 1: Spindle chuck
Protection zone data VALUES
Motion axes
X coordinate: MD 38000 = 0
Y coordinate: MD 38040 = 0
Z coordinate: MD 38080 = 0
FP1 vector
X coordinate: MD 38120 = -162
Y coordinate: MD 38160 = 0
Z coordinate: MD 38200 = -2
Dimension vector
X coordinate: MD 38240 = 324
Y coordinate: MD 38280 = 0
Z coordinate: MD 38320 = 254
Machine coordinate system
Number: MD 38400 = 1
Protection zone data BITS
Protection zone exists
SR exist.: MD 38760.0 = 1
Monitoring reference OFF
SR 1 - 8: MD 38800.0-7 = 00000000
SR 9 - 16: MD 38840.0-7 = 00000000
SR 17 - 20: MD 38880.0-7 = 00000000
SR 21 - 32: MD 38920.0-7 = 00000000
• Protection zone 2: Slide 1
Protection zone data VALUES
Motion axes
X coordinate: MD 38001 = X1
Y coordinate: MD 38041 = 0
Z coordinate: MD 38081 = Z1
FP1 vector
X coordinate: MD 38121 = 113
Y coordinate: MD 38161 = 0
Z coordinate: MD 38201 = 28
Dimension vector
X coordinate: MD 38241 = 329
Y coordinate: MD 38281 = 0
Z coordinate: MD 38321 = 344
Machine coordinate system
Number: MD 38401 = 1
© Siemens AG 1992 All Rights Reserved 6FC5197- AA50 12–325
SINUMERIK 840C (IA)
