12 Functional Descriptions 07.97
12.32.14 Example on a double-slide turning machine
Protection zone data BITS
Protection zone exists
SR exist.: MD 38761.0 = 1
Monitoring reference OFF
SR 1 - 8: MD 38801.0-7 = 00000100
SR 9 - 16: MD 38841.0-7 = 00000000
SR 17 - 20: MD 38881.0-7 = 00000000
SR 21 - 32: MD 38921.0-7 = 00000000
Protection zone 3: Turret of slide 1
Protection zone data VALUES
Motion axes
X coordinate: MD 38002 = X1
Y coordinate: MD 38042 = 0
Z coordinate: MD 38082 = Z1
FP1 vector
X coordinate: MD 38122 = -32
Y coordinate: MD 38162 = 0
Z coordinate: MD 38202 = -332
Dimension vector
X coordinate: MD 38242 = 64
Y coordinate: MD 38282 = 0
Z coordinate: MD 38322 = 334
Machine coordinate system
Number: MD 38402 = 1
Protection zone data BITS
Protection zone exists
SR exist.: MD 38762.0 = 1
Monitoring reference OFF
SR 1 - 8: MD 38802.0-7 = 00000010
SR 9 - 16: MD 38842.0-7 = 00000000
SR 17 - 20: MD 38882.0-7 = 00000000
SR 21 - 32: MD 38922.0-7 = 00000000
12–326
© Siemens AG 1992 All Rights Reserved 6FC5197- AA50
SINUMERIK 840C (IA)
