01.99 12 Functional Descriptions
12.36.8 Configurability of the conversion
Structure, syntax and the meaning of key words in the file CONFIG
1)
as follows:
Syntax: Parameter=value [//Comment]
2)
Parameter Value (entry example)
Max.
number
Meaning
DESCRIPTION ”Long text name” 76 Full name of switchover
function
3)
. This text appears in
the MMC dialog box for the
conversion function in the MDD.
REFERENCE TEA1:5002.4 The reference date helps to
decide which mode is set.
The groups TEA1, TEA2 and
TEA4 are permitted. Each
machine date of these groups
can be selected except for the
channel specific TEA4 data. The
selection of a bit is optional. Only
bit 0 to 7 can be selected.
Selection of a bit group (e.g.
5002.4-7) is not possible.
Specification of a decimal digit
(e.g. 3840/2) is not possible. The
bit specification must follow the
number without blank space.
MODES X Y 1 per
mode
Definition of the code letters for
the modes. In the form of code
letters, capital letters are exactly
one character long and separated
by commas.
Presently at least 2, at maximum
2 modes possible
The calculation is also defined
here: from X Y. By reversing the
conversion direction this line must
be changed accordingly, i.e. Y X
The arrow ( ) signifies the
conversion direction.
NAMES X:"Name X", "Y:"Name Y" 19 Status texts.
Definition of a text for each mode.
These text lines appear in the
MMC dialog box for the
conversion function in the MDD.
1) The format is line-related, column-free, tabs can be used instead of blanks.
2) Comments: They are valid from the double slash // until the end of the line.
3) Text constants: with double quotation marks ”...” are optional.
© Siemens AG 1992 All Rights Reserved 6FC5197- AA50
12–365
SINUMERIK 840C (IA)
