12 Functional Descriptions 01.99
12.36.8 Configurability of the conversion
Parameter Value (entry example)
Max.
number
Meaning
VALUES X:2, Y:5 One
assign-
ment per
mode
Assignment of the reference date
values.
The reference date value must be
defined for each mode by which
this mode should be recognized.
Only decimal values are allowed.
For bits only values 0 and 1 are
permitted.
FILES X:"FILES_X", Y:"FILES_Y" File name (name of machine data
block) which refers to the
respective status (e.g. the
METRIC file for metric etc.). A
maximum of 7 characters are
permitted. The reserved names
such as BOOT, STANDARD
STANDD_M, etc. must not be
used. The line with the code word
FILES is also written. Here, the
source name and the target name
from the MDD are stored.
TOA_ZOA X:#, Y:# This parameter is transmitted
directly to the NCK (in I code).
Here, parameter # means: #=0
Do not carry out conversion on
the NCK side.
#=1
Metric conversion of TOA and
ZOA data on the NCK side
#=2
Inch conversion of TOA and ZOA
data on the NCK side
Default setting=M:1, I:2
The following settings are also
possible: M:1:, I:1, or M:2, I:2 and
M:0, I:0
POWERON # Power On Reset
Then the parameter # means:
#=0:
No reset
#=1:
Reset
The parameter is valid in both
statuses
Default setting=1
Remark:
The indicated parameters are mandatory parameters except for the parameters TOA_ZOA
and POWERON. The order of entry as in the table above is applicable.
12–366
© Siemens AG 1992 All Rights Reserved 6FC5197- AA50
SINUMERIK 840C (IA)
