832-6063.0 * INSTALLATION SIMOSEC * REVISION 02 41
Installation
Ö Transport the transport unit as far as possible using the lifting device.
Ö Slowly lower the transport unit onto the transport roller (reinforced rollers).
Ö Push the transport unit to the mounting position.
Ö Lift the transport unit at the side edges with roller crowbars and lower it slowly onto
the mounting position.
Storage
When switchgear is not to be installed immediately, it should be unpacked, inspected
within 15 days of receipt and stored in a clean dry location. Indoor switchgear is neither
weather resistant nor drip resistant.
Ö Store SIMOSEC equipment indoors.
Ö Provide an adequate covering and place a heat source of approximately 100 watts
output within each panel to prevent condensation if it is to be kept in a humid or
unheated area.
Fig. 28: Transport with transport roller
a
Transport unit
s
Transport roller (reinforced roller)
