Getting Started
A5E37208904-003, 04/2017
21
SINAMICS V90 PN
Recommended fuse type
Type-E combination motor controller
1)
Power
supply
Frame
size
Rated
power
(kW)
CE-compliant
UL/cUL-
compliant
listed (JDDZ)
fuse
Rated
current (A)
Rated volt-
age (VAC)
Rated
power
(hp)
Article number
FSC 3.5 3NA3 807-6
(20 A)
25 A 14 to 20 380/480 4.7 3RV 2021-
4BA10
5.0 3NA3 807-6
(20 A)
25 A 14 to 20 380/480 6.7 3RV 2021-
4BA10
7.0 3NA3 810-6
(25 A)
25 A 20 to 25 380/480 9.4 3RV 2021-
4DA10
1)
The above types for Type-E combination motor controllers are listed in compliance with both CE and UL/cUL standards.
For more information about the accessories, refer to SINAMICS V90, SIMOTICS S-1FL6 Operating Instructions.
WARNING
Requirements for United States/Canadian installations (UL/cUL)
Suitable for use on a circuit capable of delivering not more than 65000 rms Symmetrical Amperes, 480 VAC maximum for
400 V variants of drives or 240 VAC maximum for 200 V variant drives, when protected by UL/cUL listed (JDDZ) fuse or
type E combination motor controller. For each frame size AA, A, B, C and D, use 75 °C copper wire only.
This equipment is capable of providing internal motor overload protection according to UL508C.
For Canadian (cUL) installations the drive mains supply must be fitted with any external recommended suppressor with the
following features:
• Surge-protective devices; device shall be a Listed Surge-protective device (Category code VZCA and VZCA7)
• Rated nominal voltage 480/277 VAC, 50/60 Hz, 3-phase
• Clamping voltage VPR = 2000 V, IN = 3kA min, MCOV = 508 VAC, SCCR = 65 kA
• Suitable for Type 2 SPD application
•
Clamping shall be provided between phases and also between phase and ground
Product maintenance
The components are subject to continuous further development within the scope of product maintenance (improvements to
robustness, discontinuations of components, etc).
These further developments are "spare parts-compatible" and do not change the article number.
In the scope of such spare parts-compatible further developments, connector positions are sometimes changed slightly. This
does not cause any problems with proper use of the components. Please take this fact into consideration in special
installation situations (e.g. allow sufficient clearance for the cable length).
Use of third-party products
This document contains recommendations relating to third-party products. Siemens accepts the fundamental suitability of
these third-party products.
You can use equivalent products from other manufacturers.
Siemens does not accept any warranty for the properties of third-party products.
