Siemens SIMOTICS S-1FL6 Compact Operating Instructions

Getting Started
28 A5E37208904-003, 04/2017
Article No.
1FL60...
42
44
61
62
64
66
67
90
92
94
96
Weight of
absolute
encoder
motor [kg]
With brake
2)
4.4/4.
5
6.2/6.
3
8.3/8.
4
11.0/9
.7
11.0/1
1.1
13.6/1
3.7
16.3/1
6.4
20.9/2
1.0
25.3/2
5.4
29.9/3
0.0
38.7/3
8.8
Without brake
2)
3.1/3.
2
4.9/5.
0
5.3/5.
4
8.0/6.
7
8.0/8.
1
10.7/1
0.8
13.3/1
3.4
14.8/1
4.9
19.3/1
9.4
23.9/2
4.0
32.7/3
2.8
1)
When the surrounding temperature is higher than 30 °C, the 1FL6096 motors with brake will have a power derating of
10%.
2)
The former value indicates the data for high inertia motors with straight connectors; the latter value indicates the data for
high inertia motors with angular connectors.
3)
Restricted emergency stop operation is permissible. Up to 2000 braking operations can be executed with 300% rotor
moment of inertia as external moment of inertia from a speed of 3000 rpm without the brake being subject to an inad-
missible amount of wear.
4)
This lifetime is only for reference. When a motor keeps running at 80% rated value and the surrounding temperature is
30 °C, the encoder lifetime can be ensured.
Note
The data of rated torque, rated power, and maximum torque in th
e above table allows a tolerance of 10%.
Power derating
For deviating conditions (surrounding temperature > 40 °C or installation altitude > 1000 m above sea level) the permissible
torque/power must be determined from the following table. Surrounding temperatures and installation altitudes are rounded
off to 5 °C and 500 m respectively.
Power derating as a function of the installation altitude and ambient temperature
Installation altitude above sea
level (m)
Surrounding temperature in °C
< 30
30 to 40
45
50
55
1000
1.07
1.00
0.96
0.92
0.87
1500 1.04 0.97 0.93 0.89 0.84
2000
1.00
0.94
0.90
0.86
0.82
2500
0.96
0.90
0.86
0.83
0.78
3000
0.92
0.86
0.82
0.79
0.75
3500
0.88
0.82
0.79
0.75
0.71
4000
0.82
0.77
0.74
0.71
0.67
2.5.3
Address of CE-authorized manufacturer
The address of CE-authorized manufacturer is as follows:
Siemens AG
Digital Factory
Motion Control
Frauenauracher Straße 80
DE-91056 Erlangen
Germany
