SIMOTICS M-1FE2 built-in motors
82 Hardware Installation Manual, 04/2020, A5E50074509B AA
Scope of delivery of the asynchronous version of the 1FE2
1
Rotor in Cu or Al version, optionally with sleeve
2
Stator without cooling jacket
3
Rating plate (type plate)
not illustrated Safety information and instruction leaflet. The URL to download the installation
instructions is provided on the instruction leaflet
not illustrated
SINAMICS converter settings and circuit diagram as adhesive label
Figure 5-2 Scope of delivery of the asynchronous version of the 1FE2
Procedure
● Check the shipment immediately for completeness and for damage.
Note
Siemens will not accept any claims r
elating to items missing from the delivery and which
are submitted at a later date.
● Register a complaint about
– any apparent transport damage with the delivery agent immediately.
– any apparent defects or missing components with the appropriate SIEMENS office
immediately.
The safety instructions are included in the scope of delivery.
Note
Store the safety instructions so they are always available.
Note
Special versions and construction variants may differ in the technical details and scope of
delivery.
