Siemens SIMOTION D425 User Manual

Technical Data
4.1 Technical data D4x5
D4x5
56 Manual, 05/2009
General technical data
Table 4- 8 Technical data (general)
Data SIMOTION
D425
SIMOTION
D435
SIMOTION
D445
SIMOTION
D445-1
Fan Optional
fan/battery module
Optional
fan/battery module
Fan/battery
module included in
scope of delivery
Double
fan/battery
module included
in scope of
delivery
Power supply
• Rated value
• Permissible
range
24 VDC
20.4 to 28.8 V
24 VDC
20.4 to 28.8 V
24 VDC
20.4 to 28.8 V
24 VDC
20.4 to 28.8 V
Current
consumption,
typically
1)
600 mA 600 mA 2 A 1 A
Starting current,
typ.
6 A 6 A 6 A 5 A
Power loss 15 W 15 W 48 W 24 W
1)
With no load on inputs/outputs, no 24 V supply via DRIVE-CLiQ or PROFIBUS
interface
Digital Inputs
Table 4- 9 Digital inputs on SIMOTION D4x5
Data SIMOTION D425 SIMOTION D435 SIMOTION D445/D445-1
Digital Inputs 8 8 8
Input voltage
• Rated value
24 VDC 24 VDC 24 VDC
• At signal "1"
15...30 15...30 15...30
• At signal "0"
-3 to +5 V -3 to +5 V -3 to +5 V
Galvanic isolation Yes, in groups of 4
1)
Yes, in groups of 4
1)
Yes, in groups of 4
1)
Current
consumption typ. at
signal level "1"
10 mA at 24 V 10 mA at 24 V 10 mA at 24 V
Input delay, max.
(hardware)
L->H: 50 µs
H -> L: 150 µs
L -> H: 50 µs
H -> L: 150 µs
L -> H: 50 µs
H -> L: 150 µs
1)
Reference potential is terminal M1 or M2
