Siemens SIMOTION D425 User Manual

Technical Data
4.1 Technical data D4x5
D4x5
Manual, 05/2009
57
Digital inputs/outputs (parameterizable)
Table 4- 10 Digital inputs/outputs on SIMOTION D4x5
Data SIMOTION D425 SIMOTION D435 SIMOTION
D445/D445-1
Number 8
Max. 6 as high-speed
inputs of measuring
inputs, max. 8 as high-
speed outputs of output
cams/DO
8
Max. 6 as high-speed
inputs of measuring
inputs, max. 8 as high-
speed outputs of output
cams/DO
8
Max. 6 as high-speed
inputs of measuring
inputs, max. 8 as high-
speed outputs of output
cams/DO
If used as an input:
• Input voltage, rated
value
24 VDC 24 VDC 24 VDC
• Input voltage with
signal "1"
15...30 15...30 15...30
• Input voltage with
signal "0"
-3 to +5 V -3 to +5 V -3 to +5 V
Galvanic isolation no no no
Current consumption
typ. at signal level "1"
10 mA at 24 V 10 mA at 24 V 10 mA at 24 V
Input
delay, max. (hardware)
L -> H: 5 µs
H -> L: 50 µs
L -> H: 5 µs
H -> L: 50 µs
L -> H: 5 µs
H -> L: 50 µs
Input of measuring
input, accuracy
(reproducibility)
5 µs 5 µs 5 µs
If used as an output
• Rated load voltage,
permissible range
24 VDC, 20.4 to 28.8 V 24 VDC, 20.4 to 28.8 V 24 VDC, 20.4 to 28.8 V
• Electrical
isolation
no no No
• Current load, max.
500 mA per output 500 mA per output 500 mA per output
• Residual current,
max.
2 mA 2 mA 2 mA
• Output delay, max.
(hardware)
1)
L->H: 400 µs
H -> L: 100 µs
L->H: 400 µs
H -> L: 100 µs
L->H: 400 µs
H -> L: 100 µs
• Output of output
cam, accuracy
Reproducibility
125 µs 125 µs 125 µs
Switching frequency of the outputs, max.
• with resistive load
100 Hz 100 Hz 100 Hz
• With inductive load
2 Hz 2 Hz 2 Hz
• For lamp load
11 Hz 11 Hz 11 Hz
Short-circuit protection yes yes yes
1)
Load 47 ohms, H = 90% V
Out
; L = 10 % V
Out
