Bits 8 only when bit 1 = 1
Bit 8 = 0
$AC_CYCLE_TIME is not deleted on jumping to program start with GOTOS
Bit 8 = 1
$AC_CYCLE_TIME is deleted on jumping to program start with GOTOS.
Bit 9 only when bits 0, 1 = 1:
Bit 9 = 0
$AC_OPERATING_TIME, $AC_CYCLE_TIME: No measurement with override = 0.
Bit 9 = 1
$AC_OPERATING_TIME, $AC_CYCLE_TIME: Measurement also with override = 0.
Bits 10 to 31
Reserved
27880 PART_COUNTER C09 K1
- Activation of workpiece counter DWORD Reset
-
808d-me42 - 0x901 0 0x0FFFFFFF 1/1 M
808d-me62 - 0x901 0 0x0FFFFFFF 1/1 M
808d-te42 - 0x901 0 0x0FFFFFFF 1/1 M
808d-te62 - 0x901 0 0x0FFFFFFF 1/1 M
808d-mte40 - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x0FFFFFFF 7/2 M
808d-mte60 - 0x0, 0x0, 0x0, 0x0,
0x0, 0x0, 0x0, 0x0...
0 0x0FFFFFFF 7/2 M
Description: The part counters can be configured with this machine data.
Note: with bit 0 = 1 and $AC_REQUIRED_PARTS less than 0, all workpiece counts
activated in this MD are frozen at the status reached.
Meaning of the individual bits:
Bits 0 - 3: Activating $AC_REQUIRED_PARTS
------------------------------------------------------------------------
Bit 0 = 1: Counter $AC_REQUIRED_PARTS is activated
Further meaning of bits 1-3 only when bit 0 =1 and $AC_REQUIRED_PARTS > 0:
Bit 1 = 0: Alarm/VDI output if $AC_ACTUAL_PARTS corresponds to $AC_REQUIRED_PARTS
Bit 1 = 1: Alarm/VDI output if $AC_SPECIAL_PARTS corresponds to $AC_REQUIRED_PARTS
Bit 2 Reserved!
Bit 3 Reserved!
Bits 4 - 7: Activating $AC_TOTAL_PARTS
-------------------------------------------------------------------------
Bit 4 = 1: Counter $AC_TOTAL_PARTS is active
Further meaning of bits 5-7 only when bit 4 =1 and $AC_REQUIRED_PARTS > 0:
Bit 5 = 0: Counter $AC_TOTAL_PARTS is incremented by 1 with a VDI output of M02/M30
Bit 5 = 1: Counter $AC_TOTAL_PARTS is incremented by 1 with output of the M command
from MD PART_COUNTER_MCODE[0]
Bit 6 = 0: $AC_TOTAL_PARTS also active with program test/block search
Bit 6 = 1: No machining $AC_TOTAL_PARTS with program test/block search
Bit 7 = 1: Counter $AC_TOTAL_PARTS is incremented by 1 on a return with GOTOS
Bits 8 - 11: Activating $AC_ACTUAL_PARTS
-------------------------------------------------------------------------
Bit 8 = 1: Counter $AC_ACTUAL_PARTS is active
Machine data
3.3 Channel-specific machine data
