13111 PROFIBUS_TRACE_TYPE EXP -
- PROFIBUS/PROFINET trace settings DWORD NEW CONF
-
808d-me42 - 0 0 3 0/0 S
808d-me62 - 0 0 3 1/1 M
808d-te42 - 0 0 3 0/0 S
808d-te62 - 0 0 3 1/1 M
808d-mte40 - 0 0 3 2/2 M
808d-mte60 - 0 0 3 2/2 M
Description: For PROFIBUS/PROFINET only:
0: Recording to the part program memory /_N_MPF_DIR/_N_SIEMDPTRC_MPF
1: Recording to mass storage /user/sinumerik/data/temp/siemdptrc.trc
2: Recording to the part program memory with runtime measurement
3: Recording of cyclic PN-NCULINK communication
13112 PROFIBUS_TRACE_FILE_SIZE EXP -
- Maximum trace file size in kbytes DWORD NEW CONF
-
808d-me42 - 40 - - 0/0 S
808d-me62 - 40 - - 1/1 M
808d-te42 - 40 - - 0/0 S
808d-te62 - 40 - - 1/1 M
808d-mte40 - 40 - - 2/2 M
808d-mte60 - 40 - - 2/2 M
Description: For PROFIBUS/PROFINET only:
0: Trace without file size limitation
>0: Trace with file size limitation
13113 PROFIBUS_TRACE_START EXP -
- Activation of PROFIBUS/PROFINET trace DWORD Immediately
-
808d-me42 - 0 0 1 0/0 S
808d-me62 - 0 0 1 1/1 M
808d-te42 - 0 0 1 0/0 S
808d-te62 - 0 0 1 1/1 M
808d-mte40 - 0 0 1 2/2 M
808d-mte60 - 0 0 1 2/2 M
Description: For PROFIBUS/PROFINET only:
0: Trace off
1: Trace on
MD13112 $MN_PROFIBUS_TRACE_FILE_SIZE > 0: Trace is automatically disabled when the
file size is reached.
13114 PROFIBUS_TRACE_START_EVENT EXP -
- Trigger conditions for PROFIBUS/PROFINET trace DWORD NEW CONF
-
808d-me42 14 0, 0, 0, 0, 0, 0, 0, 0... 0x00000000 0x111fffff 0/0 S
Machine data
3.2 General machine data
Parameter Manual
List Manual, 01/2017 81
