Page #82 background image
808d-me62 14 0, 0, 0, 0, 0, 0, 0, 0... 0x00000000 0x111fffff 1/1 M
808d-te42 14 0, 0, 0, 0, 0, 0, 0, 0... 0x00000000 0x111fffff 0/0 S
808d-te62 14 0, 0, 0, 0, 0, 0, 0, 0... 0x00000000 0x111fffff 1/1 M
808d-mte40 14 0, 0, 0, 0, 0, 0, 0, 0... 0x00000000 0x111fffff 2/2 M
808d-mte60 14 0, 0, 0, 0, 0, 0, 0, 0... 0x00000000 0x111fffff 2/2 M
Description: For PROFIBUS/PROFINET only:
The trigger frequency is configured bit-by-bit
Bits 0-15: 0x0001-0xffff: bit mask
Bits 16-23: 0x01-0x14: process data number (a maximum of 20 words are permissible)
Bits 24-27:0x01: status change 0->1
0x00: status change 1->0
Bits 28-31:0x10: send slot
0x00: receive slot
When MD13113 $MN_PROFIBUS_TRACE_START=1 and MD13114
$MN_PROFIBUS_TRACE_START_EVENT=0x0 Recording starts immediately
When MD13113 $MN_PROFIBUS_TRACE_START=1 and MD13114
$MN_PROFIBUS_TRACE_START_EVENT=0x1 Recording starts on control power on
When MD13113 $MN_PROFIBUS_TRACE_START=1 and MD13114
$MN_PROFIBUS_TRACE_START_EVENT=0x2 Recording starts on loss of the sign of life
13120 CONTROL_UNIT_LOGIC_ADDRESS N04, N10 -
- Logical address of SINAMICS CU DWORD PowerOn
-
808d-me42 1 6500, 0, 0, 0, 0, 0, 0, 0... 0 16383 ReadOnly M
808d-me62 5 0 0 8191 0/2 M
808d-te42 1 6500, 0, 0, 0, 0, 0, 0, 0... 0 16383 ReadOnly M
808d-te62 5 0 0 8191 0/2 M
808d-mte40 15 6500, 0, 0, 0, 0, 0, 0, 0... 0 16383 7/2 M
808d-mte60 15 0 0 8191 0/2 M
Description: For PROFIBUS/PROFINET, SINAMICS:
Logical I/O address of a SINAMICS-CU (Control Unit) on the PROFIBUS/PROFINET.
The cyclic DP communication with SINAMICS-CU is activated by taking over the
associated slot address from the STEP7 project. The onboard I/Os cannot be accessed
until after configuration.
13140 PROFIBUS_ALARM_ACCESS N04, N10 -
- Alarm response of PROFIBUS/PROFINET drives on power up DWORD Immediately
-
808d-me42 - 1 0 2 ReadOnly M
808d-me62 - 1 0 2 ReadOnly M
808d-te42 - 1 0 2 ReadOnly M
808d-te62 - 1 0 2 ReadOnly M
808d-mte40 - 1 0 2 2/7 M
808d-mte60 - 1 0 2 2/7 M
Description: For PROFIBUS/PROFINET only:
Specifies the time of activation for evaluation/transmission of
PROFIBUS/PROFINET node alarms or warnings
(fine diagnostics messages) on the NCK.
Affects drive alarms or warnings 380500, 380501
Machine data
3.2 General machine data
Parameter Manual
82 List Manual, 01/2017
