Operation 10.04
2.10 Automatic mode
2
 Siemens AG, 2004. All rights reserved
2-122 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
Line: Parameter is assigned by ShopMill
Type: " " Search target is ignored on this level
N no. Block number
Marker Jump marker
Text Character string
Sub-r. Subprogram call
Line Line number
Search target: Point in the program at which machining is to start
Selecting ShopMill cycle
 Load a program in "Machine Auto" operating mode (see Sec.
"Selecting a program for execution").
 Position the cursor on the desired target block.
Start
search run
 Press the "Block search" and "Start search run" softkeys.
 Where chained program blocks have several technology blocks,
select the desired technology block in the "Search run" window.
The prompt does not appear in the case of single program blocks.
 Press the "Accept" softkey.
 For chained program blocks, enter the number for the desired
starting position.
The prompt does not appear in the case of single program blocks.
 Press the "Accept" softkey.
Cycle Start
 Press the "Cycle Start" key.
ShopMill carries out all necessary default settings.
Cycle Start
 Press the "Cycle Start" key again.
The new starting position is approached. The workpiece is then
machined from the beginning of the target block.
Reset
You can abort the search by pressing the "Reset" key.
