Siemens SINUMERIK 810D Operation/Programming

1
Introduction 10.04
1.3 User interface
1
 Siemens AG, 2004. All rights reserved
1-36 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
Secondary mode
REF: Approaching a reference point
REPOS: Repositioning
INC1 ... INC10000: Fixed increment
INC_VAR: Variable increment
Channel status
RESET
Active
Interrupted
Program control
SKP: Skip G code block
DRY: Dry run feedrate
!ROV: Feedrate override only (not feedrate and rapid traverse
override)
SBL1: Single block (stop after every block that triggers a
function on the machine)
SBL2: Not possible to select in ShopMill (stop each every block)
SBL3: Single block fine (stop after every block, even within a
cycle)
M01: Programmed stop
DRF: DRF Offset
PRT: Program test
Channel operational
messages
Stop: An operator action is required.
Wait: No operator action is required.
If a dwell time is active, the remaining dwell time is displayed. It is
either displayed in seconds or as spindle revolutions.
Position display of the
axes
The actual value display in the position display refers to the SZS
coordinate system (settable zero system). The position of the active
tool relative to the workpiece zero is displayed.
Symbols used for axis display
Linear axis clamped
Rotary axis clamped
Feedrate status
Feedrate is not enabled
