4
Machine Operating Area 03.04
4.2 General functions and dis
p
la
y
s
4
Ó Siemens AG, 2004. All rights reserved
4-108 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
4.2.7 Display spindles
Function
The current spindle values (actual speed, setpoint speed, position on
oriented spindle stop and spindle override) can be displayed.
Operating sequence
"AUTO"/"MDI"/"Jog" mode is selected in the "Machine" operating
area.
The "Spindle" window appears on the screen.
The window contains the spindle setpoint and actual value, position,
setting of spindle override switch and spindle output.
or
Using the "Page" keys you can scroll up and down to display other
spindles if any are configured.
Other information
· The "Spindle" window is displayed only if at least one spindle is
configured.
· If a master spindle is configured, this is automatically displayed in
the spindle window, even if it is not the first spindle.
SW 6.2 and higher:
The following spindle states are output as symbols for the spindles
displayed in the spindle window:
· "Spindle Stop"
· "Spindle not enabled"
· "Spindle CCW direction of rotation" or "... CW"
(=Spindle running)
