03.04 Operator Components/Sequence of Operations
2.7 Hel
p
2
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 2-71
2.7 Help
Function
Whenever the symbol "i" is displayed in the dialog line, you can press
the information key
to display additional information.
A comment appears in the dialog line.
Analogous to the Windows Help, an HMI Help function is provided on
the HMIs.
(The term MMC Help still appears in the SW from time to time.) If, for
example, you have made an input error, you can select the HMI Help
to access detailed information about the error that has just occurred,
e.g. the Diagnostic Guide is displayed.
Available help functions include:
· Alarm help
Detailed information on displayed alarm/message
· MD help
Detailed information on selected MD/SD
· Editor help
Press once for information in brief and press twice for detailed
information on the command/function on which the cursor is
positioned.
By pressing the "Information" key, e.g. in the "Diagnosis" operating
area, the HMI Help to access information about the alarm that is
currently being indicated is automatically called up and displayed.
Page
down
or
Page
up
You can page through the document with the softkeys "Page up" and
"Page down",
Next entry
you jump to the next hit in the document with "Next entry".
Follow
cross ref.
Where there are cross references to other documents you can jump to
a particular point in that document with this softkey.
Go to...
You can search for any words in the document with the search
function "Go to ...".
Zoom +
or
Zoom -
With the softkeys "Zoom +" and "Zoom -" you can increase or
decrease the zoom factor in the document view,
Exit
help
with "Exit help" you return to the editor.
