03.04 "Diagnosis" Operating Area
8.3 Service dis
p
la
y
8
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 8-419
8.3.10 Displaying the version screen for cycles (from SW 6.3)
Function
The following version screens can be displayed and used to diagnose
the cycle states in SW 6.3 and higher:
· Overview of the cycle packages available on the control.
· Details of the individual packages.
· Overview of all available cycles.
· Separate overview for user, manufacturer and standard cycles.
· Definitions.
Operating sequence
Service
displays
Press softkey "Service displays".
The horizontal softkey bars change.
Versions
Open the "Version" window in the "Service displays" menu.
The following softkeys are displayed:
Package overview
Cycle
version
Package
overview
The cycle packages available on the NCK can be displayed in a
separate "Cycle version data" overview by pressing the horizontal
softkey "Version data cycles". The vertical softkey "Package overview"
is included automatically.
Related cycles can be grouped together in packages and listed in a
package list. The complete package is assigned a package name and
a version identifier. The file type of the cycle package list is .cyp
(cycle package). Package lists are named cyc_xxx.cyp and the
following standard names are defined:
Predefined package lists
Package list Cycle package
cyc_sc.cyp Standard cycles
cyc_scs.cyp Cycle support (for standard cycles)
cyc_mc.cyp Measuring cycles
cyc_mcs.cyp Measuring cycle support
cyc_mj.cyp Measuring in JOG
cyc_sm.cyp ShopMill
cyc_st.cyp ShopTurn
cyc_mt.cyp ManualTurn
cyc_c950.cyp Extended stock removal
cyc_c73.cyp Pocket surfaces with islands
cyc_iso.cyp ISO compatibility for cycles
cyc_cma.cyp Manufacturer cycles (predefined name)
cyc_cus.cyp User cycles (predefined name)
