6
"Program" Operating Area 03.04
6.5 Free contour
p
ro
g
rammin
g
6
Ó Siemens AG, 2004. All rights reserved
6-280 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
6.5.3 Contour elements
Function
Contour chain
The elements of the contour and pole, if applicable, are displayed
symbolically in the sequence in which they were programmed in a
contour chain next to the graphic window.
