7
03.04 "Services" Operating Area
7.6 Mana
e data
7
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 7-395
Other information
· No check is made to determine whether or not the file contents
may be stored under the new file type!
· The contents of a file are not altered when the file type is
converted.
· All data types may be stored in the "Clipboard" directory.
· In SW 6.3 and higher, the file type is displayed in the properties
window for network drives or disk, and the extension with 0 to 3
letters can be modified in the "Type" input field.
7.6.7 Defining and activating user data (GUD)
Function
Create a definition file for user data:
· In the "Services" operating area using the softkey "Manage
data"
· In the "Definitions" directory
Procedure
OK
Abort
If a definition file is edited in the NC, when exiting the Editor you are
prompted whether the definitions are to be set active.
Example:
"Do you want to activate the definitions from file GUD7.DEF?"
"OK" Ã A query is displayed asking if the currently active
data should be saved. "Do you want to save the
previous data for the definitions?"
"OK" Ã The GUD blocks for the definition
file to be edited are saved, the new definitions
are activated and the saved data are
reloaded.
"Abort" Ã The new definitions are activated, the old ones
are lost.
"Abort" Ã The changes to the definition file are rejected, the
associated data block is not altered.
Unload
If a definition file is unloaded, the associated data block is deleted
after a query is displayed.
