2
03.04 Operator Components/Sequence of Operations
2.6 General se
q
uence of o
p
eration
2
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 2-55
Select the workpiece/program for execution:
Program
selection
The name of the selected workpiece is displayed on the screen in field
"Program name" at the top. The program is then loaded.
2.6.2 Switch menu window
If a screen comprises several windows, you can use the "Window
selection" key to switch between the individual windows. You only
need to do this if you wish to enter data on the operator panel front.
The focus changes to the selected menu window (the header and
border of the active window appear in a different display format).
Scroll in menu window:
If the contents of a window cover several screen pages, you can use
the "Page" keys to scroll up or down through the information.
A scroll bar indicates that the contents of the window extend beyond
the visible display.
Position cursor in menu window:
You can position the cursor at the desired point in the menu window
with the "Direction keys".
