8
"Diagnosis" Operating Area 03.04
8.3 Service dis
la
8
Ó Siemens AG, 2004. All rights reserved
8-420 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Details of packages
Cycle
version
Details
Select a package in the package overview and press the vertical
softkey "Details". The following details for the selected package
appear in the "Version data" overview:
· Package name Name
· Package type Type
· Load status Loaded
· Package length Length
· Storage directory Directory (in data management)
· Date
· Version entry Version
Overview of
Cycle
version
All cycles
All
cycles
Press the vertical softkey "All cycles". The horizontal softkey "Cycle
version" is included automatically.
All available cycles of the types .com and .spf from the user cycle
(CUS.DIR), manufacturer cycle (CMA.DIR) and standard cycle
(CST.DIR) directories are displayed in the "Version data" overview
irrespective of the packages.
If a file is stored in several directories, the text color of the active
version appears in black in the editor. Inactive files are grayed out.
Cycle
version
User
User
cycles
Manufacturer
Manufac-
turer cycles
Standard
Standard
cycles
Cycles
Press the desired vertical softkey
· "User cycles" or
· "Manufacturer cycles" or
· "Standard cycles"
The horizontal softkey "Cycle version" remains active.
All files of the type .com and .spf from the user, manufacturer or
standard cycle directory are displayed in the "Version data" overview
without the package lists.
Definitions
Defi-
nitions
The definition files available on the NCK can be displayed in a
separate "Version data definitions" overview by pressing the
horizontal softkey "Definitions". All the definition files from the
DEF.DIR directory in the data management then appear in this
overview.
You can change to another version display by pressing a different
horizontal softkey.
Sort
The version information can be sorted according to the proposed
criteria in either ascending or descending order.
