03.04 Machine Operating Area
4.6 Automatic mode
4
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 4-141
Horizontal softkeys
Program
overview
The workpiece or program overview is displayed. In this area it is
possible to select programs for execution.
The memory space available on the hard disk and in the NCU is
displayed in the footer.
Vertical softkeys
Current
block
The "Current block" window is also displayed.
The current block is highlighted while the program is running.
The name of the program to which the blocks on the screen belong is
output in the window header.
Program
level
When you press softkey "Program level", the window headed
"Program level" appears instead of the "Current block" window.
The program nesting depth (P = number of passes) is displayed.
Program
level
or
Current
block
In program operation it is possible to toggle between the "Program
level" and "Current block" displays.
Program
blocks
Seven program blocks of the current program are displayed together
with the current position in the part program.
Unlike with function "Current block", the program created by the
programmer is displayed.
Other information
The other softkeys are described in the sections below.
