5
"Parameters" Operating Area 03.04
5.1 Tool data
5
Ó Siemens AG, 2004. All rights reserved
5-176 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Calculation of tool
parameters
Types 1xy (milling cutters), 2xy (drills) and 5xy (turning tools) are
calculated according to the same scheme.
Several entries exist for the geometric variables (e.g. length 1 or
radius). These are added together to produce a value (e.g. total
length 1, total radius) which is then used for the calculations.
Tool parameter
number (P)
Meaning Remarks
1 Tool type For overview see list
2 Tool point direction Only for turning tools
Geometry Length compensation
3 Length 1 Calculation according to type and
plane
4 Length 2
5 Length 3
Geometry Radius
6 Radius Does not apply to drills
7 Reserved
8 Reserved
9 Reserved
10 Reserved
11 Reserved
Wear Length and radius compensation
Radius compensation
12 Length 1
13 Length 2
14 Length 3
15 Radius
16 Reserved
17 Reserved
18 Reserved
19 Reserved
20 Reserved
