5
03.04 "Parameters" Operating Area
5.2 Tool offsets
5
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 5-183
Tool wear:
fine compensation
If you have at least the authorization which is entered in MD 9202:
USER_CLASS_TOA_WEAR, you can change the values of the tool
fine offset incrementally. The difference between the old and new
values must not exceed the limit stored in MD 9450:
WRITE_TOA_FINE_LIMIT.
Horizontal softkeys
You can select different data types with the horizontal softkeys:
Tool
offset
Selection of "Tool offset" menu
R
variables
Selection of "R variables" menu
Setting
data
Selection of "Setting data" menu
Zero
offset
Selection of "Zero offset" menu
User
data
Selection of "User data" menu
Determine
compens...
Support in determining tool offsets. This softkey is not required if the
tool management function is available.
Vertical softkeys
The vertical softkeys support data input:
T No.
+
Selection of the next tool
T No.
–
Selection of the previous tool
D No.
+
Selection of next higher offset number (cutting edge)
D No.
–
Selection of next lower offset number (cutting edge)
Delete...
Deletion of a tool or cutting edge
Go to...
Find any tool or the active tool
Overview…
List of all available tools
New ...
New cutting edge or a new tool
