5
"Parameters" Operating Area 03.04
5.3 Tool mana
ement
5
Ó Siemens AG, 2004. All rights reserved
5-194 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Location (Pl)
Location number
Location state (P)
Location state
(one column is provided for each state)
e.g.
F = Location enabled
G = Location disabled
Z = Reserved for tool in intermediate memory
B = Reserved for tool to be loaded
L = Left half location occupied
R = Right half location occupied
O = Upper half location occupied
U = Lower half location occupied
l = Left half location reserved (from SW 6.4)
r = Right half location reserved (from SW 6.4)
o = Upper half location reserved (from SW 6.4)
u = Lower half location reserved (from SW 6.4)
PTP
Type assigned to the location
ToolID
Name of the tool
Dupl
Number of replacement tool
TNo
Internal T numbers which may be needed for reloading tool data.
PTT
Type of location assigned to the tool
W (8x)
Tool status
(one column is provided for each status)
No display = Replacement tool
A = Active tool
F = Tool enabled
G = Tool disabled
M = Tool is measured
V = Prewarning limit is reached
W = Tool is being changed
P = Tool is fixed-location-coded
E = Tool has been used
R = Unloading marking ("radius")
B = Loading marking
S = Master tool
PV
Wear group assigned to the tool.
