"Parameters" Operating Area 03.04
5.3 Tool mana
g
ement
5
Ó Siemens AG, 2004. All rights reserved
5-206 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Row 9 displays the current tool for channel "HAND". There the current
value of G56 is equal to the reset value (
).
Symbols
/
The G56 reset value is TOWMCS
/ and
$SC_WEAR_TRANSFORM is set.
The current tool for channel "REV2" is indicated in row 2. The current
value of G56 on channel "REV2" deviates from the G56 reset value
(
).
Row 11 displays the current tool for channel "HAND". There the
current value of G56 is equal to the reset value (
).
