5
03.04 "Parameters" Operating Area
5.3 Tool mana
ement
5
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 5-215
Select the appropriate list via softkey:
Magazine
list
· "Magazine list"
A tool is to be physically removed from a magazine location. You
can configure whether the corresponding NC block is also
removed from the TO memory.
Select the magazine and the tool to be unloaded (select the tool
with the cursor).
or
Tool
list
· "Tool list"
The NC block is to be unloaded from the memory. Select the tool
to be unloaded (select the tool with the cursor).
Unload
Select softkey "Unload".
The vertical softkey bar changes.
Tool in
cabinet
The tool data of the selected tool are stored in the tool cabinet on the
hard disk. This allows you to load the tool with the same data again at
a later point.
Data on
CC
If a code carrier is installed, the tool data are automatically stored
there. This allows you to load the tool with the same data again at a
later point.
From
magazine
The vertical softkey bar changes.
The corresponding line is deleted from the magazine list.
The entries in the magazine number and location number columns are
removed from the tool list.
"Unload directly from spindle" is possible only if the buffer is selected
and the cursor is positioned on the location of the spindle.
To exit the screen without unloading the tool, select another display
in the vertical softkey bar before activating "Start".
Delete
tool
The tool data of the selected tool are deleted from the TO memory. If
the tool is in a magazine location, it is unloaded and deleted.
If a host computer is connected, the data are transferred to the host
computer each time a tool is deleted or unloaded.
