5
03.04 "Parameters" Operating Area
5.7 User data/user variables
GUD
PUD
LUD
5
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 5-253
Find
Select softkey "Find".
Dialog window "Find user data" appears on the screen.
The data name or a character string within the name can be entered
as the search target.
The cursor must be positioned on the user data to be found.
Find next
The next user data with the initial identifier searched for is displayed.
User data of types AXIS and FRAME are not displayed.
Only those local user data that still exist in the execution chain of the
control are displayed.
The list of local user data for the display window is updated every time
"NC Stop" is actuated. The data values are updated continuously.
Before global user data definitions can be made operative in the
control, it may be necessary to set machine data.
Other information
A description of how to define and activate user data can be found
· in Chapter "Services" Operating Area.
