6
"Program" Operating Area 03.04
6.10 Mana
e
ro
rams
6
Ó Siemens AG, 2004. All rights reserved
6-342 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Set up programs/data in a workpiece directory
This section explains how you can set up a new file for a part program
or workpiece.
Operating sequence
The current overview of the workpiece directories stored on the NC
appears.
Position the cursor on the required workpiece and open it.
An overview will be displayed listing the data and programs that have
already been created in the workpiece directory. If no data is
available, the program overview is blank.
New
A dialog box appears when you select softkey "New".
Enter the new file name.
You can also enter the corresponding file type using the "Insert key".
Some of the possible file types are listed below:
File type Meaning
.WPD Workpiece
.MPF Part program (main program file)
.SPF Subroutine (subprogram file)
.JOB Job list
.GUD Channel user data
.IKA Compensation data
.INI Initialization program
.UFR Work offset/frame
.TOP Tool plan
.TOA Tool offsets (tool offset active)
.TMA Magazine data
.TEA Machine data (testing data active)
.TCM Tool plan reformatted (for SINTDI)
.STP MCSE data
.SEA Setting data active
.RPA Arithmetic parameters
.PRO Protection zones
.DAT Time calculation
