7
"Services" Operating Area 03.04
7.2 Director
structure
7
Ó Siemens AG, 2004. All rights reserved
7-362 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Copy file from NC memory:
· The file exists on the NCK and is overwritten when you select "OK"
if the name/data type are to remain unchanged!
· The file exists on the NCK. When you select "OK" a copy is
created if the name/file type are to remain unchanged!
Copy a workpiece:
· The workpiece already exists. When you select "OK" a copy of the
workpiece is created if a new name is not specified!
Copy a directory:
· The directory already exists. When you select "OK" the contents
are overwritten if a new name is not specified!
· The directory already exists. When you select "OK" the contents
are overwritten if the directory with a fixed data type cannot be
changed.
Copy a file of data type main program (MPF):
· The file cannot be created at this location under its original "main
program" data type!
Vertical softkeys for "Save as"
All without
query
Press the "All without query" softkey if all existing files in the current
directory are to be created with new names without a "Save as"
dialog. All files for which the original file type can be created
are automatically converted to the specified data type.
Skip file
Press the "Skip file" softkey if the copy operation is to be continued
with the next file.
Abort
This key cancels the entire copy operation.
OK
An existing file is either overwritten or, if the name or file type was
changed, saved with the new name. The "OK" softkey is disabled if
you have to enter a new name.
Display
The file tree display can be modified by the user:
· Display of file properties
· Number of displayed directories
Data management
Limit of data management (DM):
A maximum of 100,000 files can be stored in the following data
management directories:
· Workpieces
