Operating sequence
Service
displays
Select the menu headed "Service displays".
The softkey bars change. The softkeys in the horizontal menu bar
allow you to select the various service displays. The vertical softkeys
are context-sensitive according to the service display. You can use
them to select the axis configuration or define or change a specific
axis selection.
Change
selection...
Define a specific axis selection
Press the "Change selection..." softkey in the "Service overview"
window.
Change configurations
You can compose your own axis list in the "Change configurations"
menu. The available axes can be entered in the axis list in any order.
Example:
Suppose you want 4 axes to appear in the order 1 3 5 8.
The existing axis list appears in "Change configurations", e.g. 1 7 5
Use the "Insert" key to enter the new axes with a space between each
axis number: 1 3 5 8
Axis numbers outside the valid range from 1 to 31 are deleted. A
default list ("1 2 3 4") is displayed if you try to enter an empty list.
Abort
OK
Returns you to the main "Service overview" menu: the changes to the
current axis list are not saved.
Returns you to the main "Service overview" menu: the changes to the
current axis list are saved and applied with the displayed information.
Select
axes
Display selected axes
Press the vertical softkey "Select axes".
The window changes to the main "Service overview" menu and the
previous axis selection is displayed.
Active
axes
Display active axes
Press the vertical softkey "Active axis" in the "Service overview"
window. The active axes appear in the main "Service overview" menu.
All
axes
Display all axes
Press the vertical softkey "All axes" in the "Service overview" window.
The maximum set of possible axes appears in the main "Service
overview" menu.
