8
"Diagnosis" Operating Area 03.04
8.4 PLC status
8
Ó Siemens AG, 2004. All rights reserved
8-426 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Change the operand, the format or the value.
Delete:
Delete
The entries for the selected operand (formats and values) are deleted.
A query window is opened.
Undo changes:
Undo
changes:
Cyclic updating is continued; the entered values are not transferred to
the PLC.
Accept:
Accept
The entered values are transferred to the PLC. Cyclic updating is
continued.
Other information
Press the "information key".
A description of the permissible input syntax for the PLC status
display is overlaid.
