C References
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator’s Guide HMI Advanced (BAD) – 03.04 Edition A-503
c) Software
/FB1/
SINUMERIK 840D/840Di/810D/FM-NC (03.04 Edition)
Description of Functions Basic Machine (Part 1)
(the various sections are listed below)
Order No.: 6FC5297-7AC20-0BP0
A2 Various Interface Signals
A3 Axis Monitoring, Protection Zones
B1 Continuous Path Mode, Exact Stop and Look Ahead
B2 Acceleration
D1 Diagnostic Tools
D2 Interactive Programming
F1 Travel to Fixed Stop
G2 Velocities, Setpoint/Actual-Value Systems, Closed-Loop Control
H2 Output of Auxiliary Functions to PLC
K1 Mode Group, Channel, Program Operation Mode
K2 Axes, Coordinate Systems, Frames, Actual-Value System for
Workpiece, External Zero Offset
K4 Communication
N2 EMERGENCY STOP
P1 Transverse Axes
P3 Basic PLC Program
R1 Reference Point Approach
S1 Spindles
V1 Feeds
W1 Tool Offset
/FB2/
SINUMERIK 840D/840Di/810D (03.04 Edition)
Description of Functions Extended Functions (Part 2)
including FM-NC: Turning, Stepper Motor
(the various sections are listed below)
Order No.: 6FC5297-7AC30-0BP0
A4 Digital and Analog NCK I/Os
B3 Several Operator Panels and NCUs
B4 Operation via PG/PC
F3 Remote Diagnostics
H1 JOG with/without Handwheel
K3 Compensations
K5 Mode Groups, Channels, Axis Replacement
L1 FM-NC Local Bus
M1 Kinematic Transformation
M5 Measurement
N3 Software Cams, Position Switching Signals
N4 Punching and Nibbling
P2 Positioning Axes
P5 Oscillation
R2 Rotary Axes
S3 Synchronous Spindles
S5 Synchronized Actions (up to and including SW 3/higher/FBSY/)
S6 Stepper Motor Control
S7 Memory Configuration
T1 Indexing Axes
W3 Tool Change
W4 Grinding
