2
03.04 Operator Components/Sequence of Operations
2.7 Hel
2
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 2-75
Transfer
to editor
If transfer is possible, the instruction selected in the overview is
inserted directly in the part program with "Transfer to editor".
If an instruction selected with context sensitivity active is different to
the programmed instruction, the programmed instruction is
overwritten.
If extended context sensitivity is not active or if a different selection is
displayed with "Find", "Headings" or "General overview", the selected
instruction text is inserted in the part program behind the instruction
marked by the cursor.
Exit
help
As an alternative to returning to the Editor by transferring an entry,
this softkey can be selected to close the Help window and return to
the part program writing screen.
Apart from context-sensitive help, it is also possible to search
independently of context for instructions, descriptive texts or topics.
General
overview
With "General overview" a full overview of the instructions and
relevant descriptive text stored in the help system is displayed.
Headings
With "Headings" the stored headings are listed for which a functional
grouping of the instructions can be displayed.
To select a heading, you can either use the cursor keys or enter the
heading number in an input box.
Show
heading
If a heading is selected and you press "Input" or the softkey "Show
heading", the instructions belonging to the selected heading are
displayed.
