10.10 Automatic controller setting (only MMC 103, SW 4.3 and higher)
10-237
 Siemens AG 2000 All Rights Reserved
SINUMERIK 840D Installation and Start-Up Guide (IAD) – 04.00 Edition
1
2
Start mech.
measurement
part 2?
SK “OK”
Confirm NC Start prompt
Caution:
When you activate NC Start, the
axis starts to move!
SK “Parameter”
Enter measur.
parameters
SK “Cancel”
(discard
changes)
SK “OK”
(accept
values)
Start mea-
surement
of current
control
loop?
SK “OK”
Confirm NC Start prompt
Caution:
When you activate NC Start, the
axis is operated in current control
mode!
SK “Parameter”
Enter measur.
parameters
SK “Cancel”
(discard
changes)
SK “OK”
(accept
values)
10 Drive Optimization with Start-Up Tool
05.9805.98

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
