The switch positions 9 and 10 guarantee the PROFINET functionality of the module and must
always be switched "on".
DCP mode
In this mode, there is no default device name.
The device name must be set using initialization and remains saved on the I/O module. It is
󹪝rst deleted when the factory setting is restored, e.g. using STEP 7 (TIA Portal).
Table 12-21 General settings with switch S1
1 2 3 4 5 6 7 8 9 10 Meaning
on on on on on on on on   DCP mode
Default device names
The switch positions 1 to 8 de󹪝ne the default device name of the I/O module.
There are up to 128 default device names. If these default device names are used, there is no
need for initialization.
These device names are required for the SINUMERIK 828D. If you want to operate the I/O
module at another controller, e.g. SINUMERIK ONE, then use the DCP mode.
Note
The default device names cannot be recon󹪝gured, for example with the TIA Portal "Assign device
name" function.
If you are connecting the I/O module to a SINUMERIK control as a PROFINET component, make
sure that this functionality is supported by the associated control.
Table 12-22 Default device name with switch S1
1 2 3 4 5 6 7 8 9 10 Default device name
on on on on on on on o󹪜   pp72x48pn127
o󹪜 on on on on on on o󹪜   pp72x48pn126
on o󹪜 on on on on on o󹪜   pp72x48pn125
o󹪜 o󹪜 on on on on on o󹪜   pp72x48pn124
on on o󹪜 on on on on o󹪜   pp72x48pn123
o󹪜 on o󹪜 on on on on o󹪜   pp72x48pn122
on o󹪜 o󹪜 on on on on o󹪜   pp72x48pn121
o󹪜 o󹪜 o󹪜 on on on on o󹪜   pp72x48pn120
          
on on on o󹪜 on on on o󹪜   pp72x48pn119
o󹪜 on on o󹪜 on on on o󹪜   pp72x48pn118
on o󹪜 on o󹪜 on on on o󹪜   pp72x48pn117
o󹪜 o󹪜 on o󹪜 on on on o󹪜   pp72x48pn116
on on o󹪜 o󹪜 on on on o󹪜   pp72x48pn115
o󹪜 on o󹪜 o󹪜 on on on o󹪜   pp72x48pn114
on o󹪜 o󹪜 o󹪜 on on on o󹪜   pp72x48pn113
Connectable components
12.2PP 72/48D PN and PP 72/48D 2/2A PN
