Note
If a Pt100 element is accidentally not connected in this operating mode and an input voltage
higher than 0.25 V is connected, the analog module automatically switches to the "No operating
mode" operating mode and resets the gain factor to "1". This is signalized in Status Word 0
(channel-speci󹪝c) in the input image. In addition, a corresponding error code is output for
the diagnostics at a counter value of "2" (Page140).
In the case of operation without a Pt100 element, a slightly negative voltage may be applied,
which results in an error/fault status for the module. Here, the "PNFault" LED and the status byte
1 are to be observed.
Analog outputs
Table 12-33 Measured values in the "voltage output" operating mode
16-bit value (hex.) 16-bit value (dec.) Factor Voltage value [V]
Over󹪞ow - Deactivation
Overrange - Up to 10.5V
0x6666 26214 


0.00038
10V
0x4CD1 19665 7.5V
0x199B 6555 2.5V
0x0000 0 0V
0xE665 -6555 -2.5V
0xB32F -19665 -7.5V
0x999A -26214 -10V
Underrange - Up to -10.5V
Under󹪞ow - Deactivation
Table 12-34 Measured values in the "current output" operating mode
16-bit value (hex.) 16-bit value (dec.) Factor Current value [mA]
Over󹪞ow - Deactivation
Overrange - 20.2mA
0x6666 26214 


0.00076
20mA
0x4CD1 19665 15mA
0x199B 6555 5mA
0x0000 0 0mA
0xE665 -6555 -5mA
0xB32F -19665 -15mA
0x999A -26214 -20mA
Underrange - -20.2mA
Under󹪞ow - Deactivation
Connectable components
12.2PP 72/48D PN and PP 72/48D 2/2A PN
NCU 1750
Equipment Manual, 10/2023, A5E45627807B AH 137
