Mounting and Commissioning
3.1 Mounting and Connections
SIPROTEC, 7SJ62/64, Manual
C53000-G1140-C207-2, Release date 01.2008
418
Pickup Voltages of BI6 to BI7
Table 3-18 Jumper settings for Pickup Voltages of the binary inputs BI6 and BI7 on the input/output board
C-I/O-11
1)
Factory settings for devices with power supply voltages of 24 VDC to 125 VDC
2)
Factory settings for devices with power supply voltages of 110 to 250 VDC and 115 VAC or 115 to 230 VAC
3)
Use only with pickup voltages 220 or 250 VDC
Jumpers X71, X72 and X73 on the input/output board C-I/O-11 are used to set the bus address and must not
be changed. The following table lists the jumper presettings.
Mounting location:
with housing size
1
/
3
Serial no. 2 in Figure 3-4, slot 19
with housing size
1
/
2
Serial no. 2 in Figure 3-5, slot 33
with housing size
1
/
1
Serial no. 2 in Figure 3-6, slot 33 on right side
Bus Address
Table 3-19 Jumper Settings of Bus Addresses of Input/Output Board C–I/O-11 for 7SJ64
Binary Input Jumper 19 VDC Pickup
1)
88 VDC Pickup
2)
176 VDC Pickup
3)
BI6 X21 L M H
BI7 X22 L M H
Jumper Presetting
X71 1-2 (H)
X72 1-2 (H)
X73 2-3 (L)
