4 Technical Data
428
7UT613/63x Manual
C53000-G1176-C160-2
DNP3.0 Fibre Optical Link
ST–connector transmit-
ter/receiver
FOC connector type
Connection for flush mounted
case
rear panel, mounting location
„B“
Connection for surface-
mounted case
only with external converter;
in the inclined housing on the
case bottom
Transmission speed up to 19,200 Baud
Optical wavelength λ = 820 nm
Laser class 1 acc. to
EN 60825-1/-2
Using glass fibre 50/125 µm or
using glass fibre 62.5/125 µm
Permissible optical signal at-
tenuation
max. 8 dB using glass fibre
62.5/125 µm
Maximum bridgeable
distance
1.5 km
MODBUS RS485
rear panel, mounting loca-
tion „B“
9-pole DSUB miniature
socket
Connection for flush-mounted housing
Connector for surface mounted
housing
in the inclined housing on the
case bottom
Test Voltage 500 V; 50 Hz
Transmission speed Up to 19 200 Baud
Maximum bridgeable
distance
1 km
MODBUS FO
ST–connector transmit-
ter/receiver
FOC connector type
Connection for flush-mounted
housing
Rear panel, mounting location
„B“
Connector for surface mounted
housing
only with external converter;
in the inclined housing on the
case bottom
Transmission speed Up to 19 200 Baud
optical wavelength λ = 820 nm
Laser class 1 according to
EN 60825-1/-2
Using glass fibre 50/125 µm or
using glass fibre 62.5/125 µm
Permissible optical signal at-
tenuation
Max. 8 dB, with glass fibre
62.5/125 µm
Maximum bridgeable
distance
1.5 km
Ethernet electrical (EN100)
for IEC 61850 and DIGSI
Connection for flush-mounted
housing
rear panel, mounting location
"B"
2 x RJ45 female connector
100BaseT acc. to IEEE802.3
for surface-mounting case in the inclined housing on the
case bottom
Test voltage (regarding con-
nector)
500 V; 50 Hz
Transmission speed 100 MBit/s
bridgeable distance 20 m
