4.1 General
429
7UT613/63x Manual
C53000-G1176-C160-2
Additional Interface (optional)
Time Synchronisation Interface
Ethernet optical (EN 100)
for IEC 61850 and DIGSI
FOC connector type ST–connector transmitter/re-
ceiver
Connection for flush-mounted
housing
Rear panel, mounting location
"B"
for surface-mounting case not available
optical wavelength λ = 1350 nm
Transmission speed 100 MBit/s
Laser class 1 according to
EN 60825-1/-2
Using
glass fibre 50/125 µm
or using
glass fibre 62.5/125 µm
permissible optical signal atten-
uation
max. 5 dB, with glass fibre
62.5/125 µm
bridgeable distance max. 800 m (0.94 miles)
RS485
FOC
acc. to
ordered version
isolated interface for connection of an RTD-box
RS485 Connection for flush mounted
case
Rear panel, mounting location
„C“,
9-pole DSUB port
Connection for surface
mounted case
in the inclined housing on the
case bottom
Test voltage 500 V; 50 Hz
Transmission speed 9,600 Bd
Maximum bridgeable
distance
1,000 m (3300 ft)
Optical fibre (FO) FO connector type ST connector
Connection for flush mounted
case
Rear panel, mounting location
„B“
Connection for surface
mounted case
in the inclined housing on the
case bottom
Optical wavelength λ = 820 nm
Laser class 1 according to EN
60825-1/-2
Using glass fibre 50/125 µm or
using glass fibre 62.5/125 µm
Permissible optical signal at-
tenuation
max. 8 dB using glass fibre
62.5/125 µm
Maximum bridgeable
distance
1,500 m
Character idle state Selectable: factory setting
„Light off“
Time Synchronisation DCF 77 / IRIG B Signal
(telegram format IRIG-B000)
Connection for flush-mounted
housing
Rear panel, mounting location „A“;
9-pin DSUB port
for surface-mounting case at two-tier terminals on the case bottom
