Siemens SIPROTEC 7UT63 series User Manual

A.8 Settings
555
7UT613/63x Manual
C53000-G1176-C160-2
226 ASSIGNM. 5M,2S P.System Data 1 M1+M2+M3,M4+M5
M1+M2,M3+M4+M5
M1+M2+M3+M4,M5
M1,M2+M3+M4+M5
M1+M2+M3,M4+M5 Assignment at 5 as-
sig.Meas.Loc./ 2 Sides
227 ASSIGNM. 5M,3S P.System Data 1 M1+M2,M3+M4,M5
M1+M2,M3,M4+M5
M1,M2+M3,M4+M5
M1+M2+M3,M4,M5
M1,M2+M3+M4,M5
M1,M2,M3+M4+M5
M1+M2,M3+M4,M5 Assignment at 5 as-
sig.Meas.Loc./ 3 Sides
228 ASSIGNM. 5M,4S P.System Data 1 M1+M2,M3,M4,M5
M1,M2+M3,M4,M5
M1,M2,M3+M4,M5
M1,M2,M3,M4+M5
M1+M2,M3,M4,M5 Assignment at 5 as-
sig.Meas.Loc./ 4 Sides
229 ASSIGNM. 5M,5S P.System Data 1 M1,M2,M3,M4,M5 M1,M2,M3,M4,M5 Assignment at 5 as-
sig.Meas.Loc./ 5 Sides
230 ASSIGNM. ERROR P.System Data 1 No AssigMeasLoc
No of sides
without Assignment Error
241 SIDE 1 P.System Data 1 auto-connected auto-connected Side 1 is assigned to
242 SIDE 2 P.System Data 1 auto-connected auto-connected Side 2 is assigned to
243 SIDE 3 P.System Data 1 auto-connected
compensation
earth.electrode
auto-connected Side 3 is assigned to
244 SIDE 4 P.System Data 1 auto-connected
compensation
earth.electrode
compensation Side 4 is assigned to
251 AUX. CT IX1 P.System Data 1 Not connected
conn/not assig.
Side 1 earth
Side 2 earth
Side 3 earth
Side 4 earth
MeasLoc.1 earth
MeasLoc.2 earth
MeasLoc.3 earth
MeasLoc.4 earth
Not connected Auxiliary CT IX1 is used as
252 AUX. CT IX2 P.System Data 1 Not connected
conn/not assig.
Side 1 earth
Side 2 earth
Side 3 earth
Side 4 earth
MeasLoc.1 earth
MeasLoc.2 earth
MeasLoc.3 earth
MeasLoc.4 earth
Not connected Auxiliary CT IX2 is used as
253 AUX. CT IX3 P.System Data 1 Not connected
conn/not assig.
Side 1 earth
Side 2 earth
Side 3 earth
Side 4 earth
MeasLoc.1 earth
MeasLoc.2 earth
MeasLoc.3 earth
MeasLoc.4 earth
Not connected Auxiliary CT IX3 is used as
254 AUX. CT IX4 P.System Data 1 Not connected
conn/not assig.
Side 1 earth
Side 2 earth
Side 3 earth
Side 4 earth
Side 5 earth
MeasLoc.1 earth
MeasLoc.2 earth
MeasLoc.3 earth
MeasLoc.4 earth
MeasLoc.5 earth
Not connected Auxiliary CT IX4 is used as
255 AUX CT IX3 TYPE P.System Data 1 1A/5A input
sensitiv input
1A/5A input Type of auxiliary CT IX3
256 AUX CT IX4 TYPE P.System Data 1 1A/5A input
sensitiv input
1A/5A input Type of auxiliary CT IX4
Addr. Parameter Function C Setting Options Default Setting Comments
