A Appendix
556
7UT613/63x Manual
C53000-G1176-C160-2
261 VT SET P.System Data 1 Not connected
Side 1
Side 2
Side 3
Measuring loc.1
Measuring loc.2
Measuring loc.3
Busbar
Measuring loc.1 VT set UL1, UL2, UL3 is as-
signed
262 VT U4 P.System Data 1 Not connected
conn/not assig.
Side 1
Side 2
Side 3
Measuring loc.1
Measuring loc.2
Measuring loc.3
Busbar
Measuring loc.1 VT U4 is assigned
263 VT U4 TYPE P.System Data 1 Udelta transf.
UL1E transform.
UL2E transform.
UL3E transform.
UL12 transform.
UL23 transform.
UL31 transform.
Ux transformer
Udelta transf. VT U4 is used as
270 Rated Frequency P.System Data 1 50 Hz
60 Hz
16,7 Hz
50 Hz Rated Frequency
271 PHASE SEQ. P.System Data 1 L1 L2 L3
L1 L3 L2
L1 L2 L3 Phase Sequence
276 TEMP. UNIT P.System Data 1 Celsius
Fahrenheit
Celsius Unit of temperature measure-
ment
302 CHANGE Change Group Group A
Group B
Group C
Group D
Binary Input
Protocol
Group A Change to Another Setting
Group
311 UN-PRI SIDE 1 P.System Data 1 0.4 .. 800.0 kV 110.0 kV Rated Primary Voltage Side 1
312 SN SIDE 1 P.System Data 1 0.20 .. 5000.00 MVA 38.10 MVA Rated Apparent Power of Transf.
Side 1
313 STARPNT SIDE 1 P.System Data 1 Earthed
Isolated
Earthed Starpoint of Side 1 is
314 CONNECTION S1 P.System Data 1 Y
D
Z
Y Transf. Winding Connection Side
1
321 UN-PRI SIDE 2 P.System Data 1 0.4 .. 800.0 kV 11.0 kV Rated Primary Voltage Side 2
322 SN SIDE 2 P.System Data 1 0.20 .. 5000.00 MVA 38.10 MVA Rated Apparent Power of Transf.
Side 2
323 STARPNT SIDE 2 P.System Data 1 Earthed
Isolated
Earthed Starpoint of Side 2 is
324 CONNECTION S2 P.System Data 1 Y
D
Z
Y Transf. Winding Connection Side
2
325 VECTOR GRP S2 P.System Data 1 0
1
2
3
4
5
6
7
8
9
10
11
0 Vector Group Numeral of Side 2
331 UN-PRI SIDE 3 P.System Data 1 0.4 .. 800.0 kV 11.0 kV Rated Primary Voltage Side 3
332 SN SIDE 3 P.System Data 1 0.20 .. 5000.00 MVA 10.00 MVA Rated Apparent Power of Transf.
Side 3
333 STARPNT SIDE 3 P.System Data 1 Earthed
Isolated
Earthed Starpoint of Side 3 is
Addr. Parameter Function C Setting Options Default Setting Comments
