A.8 Settings
557
7UT613/63x Manual
C53000-G1176-C160-2
334 CONNECTION S3 P.System Data 1 Y
D
Z
Y Transf. Winding Connection Side
3
335 VECTOR GRP S3 P.System Data 1 0
1
2
3
4
5
6
7
8
9
10
11
0 Vector Group Numeral of Side 3
341 UN-PRI SIDE 4 P.System Data 1 0.4 .. 800.0 kV 11.0 kV Rated Primary Voltage Side 4
342 SN SIDE 4 P.System Data 1 0.20 .. 5000.00 MVA 10.00 MVA Rated Apparent Power of Transf.
Side 4
343 STARPNT SIDE 4 P.System Data 1 Earthed
Isolated
Earthed Starpoint of Side 4 is
344 CONNECTION S4 P.System Data 1 Y
D
Z
Y Transf. Winding Connection Side
4
345 VECTOR GRP S4 P.System Data 1 0
1
2
3
4
5
6
7
8
9
10
11
0 Vector Group Numeral of Side 4
351 UN-PRI SIDE 5 P.System Data 1 0.4 .. 800.0 kV 11.0 kV Rated Primary Voltage Side 5
352 SN SIDE 5 P.System Data 1 0.20 .. 5000.00 MVA 10.00 MVA Rated Apparent Power of Transf.
Side 5
353 STARPNT SIDE 5 P.System Data 1 Earthed
Isolated
Earthed Starpoint of Side 5 is
354 CONNECTION S5 P.System Data 1 Y
D
Z
Y Transf. Winding Connection Side
5
355 VECTOR GRP S5 P.System Data 1 0
1
2
3
4
5
6
7
8
9
10
11
0 Vector Group Numeral of Side 5
361 UN GEN/MOTOR P.System Data 1 0.4 .. 800.0 kV 21.0 kV Rated Primary Voltage Genera-
tor/Motor
362 SN GEN/MOTOR P.System Data 1 0.20 .. 5000.00 MVA 70.00 MVA Rated Apparent Power of the
Generator
370 UN BUSBAR P.System Data 1 0.4 .. 800.0 kV 110.0 kV Rated Primary Voltage Busbar
371 I PRIMARY OP. P.System Data 1 1 .. 100000 A 200 A Primary Operating Current of
Busbar
372 I PRIMARY OP S1 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current Side
1
373 I PRIMARY OP S2 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current Side
2
374 I PRIMARY OP S3 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current Side
3
375 I PRIMARY OP S4 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current Side
4
Addr. Parameter Function C Setting Options Default Setting Comments
