A Appendix
558
7UT613/63x Manual
C53000-G1176-C160-2
376 I PRIMARY OP S5 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current Side
5
381 I PRIMARY OP 1 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current End 1
382 I PRIMARY OP 2 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current End 2
383 I PRIMARY OP 3 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current End 3
384 I PRIMARY OP 4 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current End 4
385 I PRIMARY OP 5 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current End 5
386 I PRIMARY OP 6 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current End 6
387 I PRIMARY OP 7 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current End 7
388 I PRIMARY OP 8 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current End 8
389 I PRIMARY OP 9 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current End 9
390 I PRIMARY OP 10 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current End
10
391 I PRIMARY OP 11 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current End
11
392 I PRIMARY OP 12 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current End
12
396 PHASE SELECTION P.System Data 1 Phase 1
Phase 2
Phase 3
Phase 1 Phase selection
403 I PRIMARY OP M3 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current Meas.
Loc. 3
404 I PRIMARY OP M4 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current Meas.
Loc. 4
405 I PRIMARY OP M5 P.System Data 1 1 .. 100000 A 200 A Primary Operating Current Meas.
Loc. 5
408 UN-PRI M3 P.System Data 1 0.4 .. 800.0 kV 110.0 kV Rated Primary Voltage Measur-
ing Loc. 3
409 UN-PRI U4 P.System Data 1 0.4 .. 800.0 kV 110.0 kV Rated Primary Voltage U4
413 REF PROT. AT P.System Data 1 Side 1
Side 2
Side 3
Side 4
Side 5
auto-connected
n.assigMeasLoc3
n.assigMeasLoc4
n.assigMeasLoc5
Side 1 Restricted earth fault prot. as-
signed to
414 REF PROT. 2 AT P.System Data 1 Side 1
Side 2
Side 3
Side 4
Side 5
auto-connected
n.assigMeasLoc3
n.assigMeasLoc4
n.assigMeasLoc5
Side 1 Restricted earth fault prot2 as-
signed to
420 DMT/IDMT Ph AT P.System Data 1 Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 DMT / IDMT Phase assigned to
422 DMT/IDMT 3I0 AT P.System Data 1 Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 DMT / IDMT 3I0 assigned to
Addr. Parameter Function C Setting Options Default Setting Comments
