Siemens SIPROTEC 7UT63 series User Manual

A Appendix
560
7UT613/63x Manual
C53000-G1176-C160-2
470 BREAKER FAIL.AT P.System Data 1 Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Ext. switchg. 1
Side 1 Breaker Failure Protection as-
signed to
471 BREAKER FAIL2AT P.System Data 1 Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Ext. switchg. 1
Side 1 Breaker Failure Protection 2 as-
signed to
511 STRPNT->OBJ M1 P.System Data 1 YES
NO
YES CT-Strpnt. Meas. Loc.1 in Dir. of
Object
512 IN-PRI CT M1 P.System Data 1 1 .. 100000 A 200 A CT Rated Primary Current Meas.
Loc. 1
513 IN-SEC CT M1 P.System Data 1 1A
5A
1A CT Rated Secondary Current
Meas. Loc. 1
521 STRPNT->OBJ M2 P.System Data 1 YES
NO
YES CT-Strpnt. Meas. Loc.2 in Dir. of
Object
522 IN-PRI CT M2 P.System Data 1 1 .. 100000 A 2000 A CT Rated Primary Current Meas.
Loc. 2
523 IN-SEC CT M2 P.System Data 1 1A
5A
1A CT Rated Secondary Current
Meas. Loc. 2
531 STRPNT->OBJ M3 P.System Data 1 YES
NO
YES CT-Strpnt. Meas. Loc.3 in Dir. of
Object
532 IN-PRI CT M3 P.System Data 1 1 .. 100000 A 2000 A CT Rated Primary Current Meas.
Loc. 3
533 IN-SEC CT M3 P.System Data 1 1A
5A
1A CT Rated Secondary Current
Meas. Loc. 3
541 STRPNT->OBJ M4 P.System Data 1 YES
NO
YES CT-Strpnt. Meas. Loc.4 in Dir. of
Object
542 IN-PRI CT M4 P.System Data 1 1 .. 100000 A 2000 A CT Rated Primary Current Meas.
Loc. 4
543 IN-SEC CT M4 P.System Data 1 1A
5A
1A CT Rated Secondary Current
Meas. Loc. 4
551 STRPNT->OBJ M5 P.System Data 1 YES
NO
YES CT-Strpnt. Meas. Loc.5 in Dir. of
Object
552 IN-PRI CT M5 P.System Data 1 1 .. 100000 A 2000 A CT Rated Primary Current Meas.
Loc. 5
553 IN-SEC CT M5 P.System Data 1 1A
5A
1A CT Rated Secondary Current
Meas. Loc. 5
561 STRPNT->BUS I1 P.System Data 1 YES
NO
YES CT-Starpoint I1 in Direction of
Busbar
562 IN-PRI CT I1 P.System Data 1 1 .. 100000 A 200 A CT Rated Primary Current I1
563 IN-SEC CT I1 P.System Data 1 1A
5A
0.1A
1A CT Rated Secondary Current I1
571 STRPNT->BUS I2 P.System Data 1 YES
NO
YES CT-Starpoint I2 in Direction of
Busbar
572 IN-PRI CT I2 P.System Data 1 1 .. 100000 A 200 A CT Rated Primary Current I2
573 IN-SEC CT I2 P.System Data 1 1A
5A
0.1A
1A CT Rated Secondary Current I2
581 STRPNT->BUS I3 P.System Data 1 YES
NO
YES CT-Starpoint I3 in Direction of
Busbar
582 IN-PRI CT I3 P.System Data 1 1 .. 100000 A 200 A CT Rated Primary Current I3
Addr. Parameter Function C Setting Options Default Setting Comments
