A.8 Settings
561
7UT613/63x Manual
C53000-G1176-C160-2
583 IN-SEC CT I3 P.System Data 1 1A
5A
0.1A
1A CT Rated Secondary Current I3
591 STRPNT->BUS I4 P.System Data 1 YES
NO
YES CT-Starpoint I4 in Direction of
Busbar
592 IN-PRI CT I4 P.System Data 1 1 .. 100000 A 200 A CT Rated Primary Current I4
593 IN-SEC CT I4 P.System Data 1 1A
5A
0.1A
1A CT Rated Secondary Current I4
601 STRPNT->BUS I5 P.System Data 1 YES
NO
YES CT-Starpoint I5 in Direction of
Busbar
602 IN-PRI CT I5 P.System Data 1 1 .. 100000 A 200 A CT Rated Primary Current I5
603 IN-SEC CT I5 P.System Data 1 1A
5A
0.1A
1A CT Rated Secondary Current I5
611 STRPNT->BUS I6 P.System Data 1 YES
NO
YES CT-Starpoint I6 in Direction of
Busbar
612 IN-PRI CT I6 P.System Data 1 1 .. 100000 A 200 A CT Rated Primary Current I6
613 IN-SEC CT I6 P.System Data 1 1A
5A
0.1A
1A CT Rated Secondary Current I6
621 STRPNT->BUS I7 P.System Data 1 YES
NO
YES CT-Starpoint I7 in Direction of
Busbar
622 IN-PRI CT I7 P.System Data 1 1 .. 100000 A 200 A CT Rated Primary Current I7
623 IN-SEC CT I7 P.System Data 1 1A
5A
0.1A
1A CT Rated Secondary Current I7
631 STRPNT->BUS I8 P.System Data 1 YES
NO
YES CT-Starpoint I8 in Direction of
Busbar
632 IN-PRI CT I8 P.System Data 1 1 .. 100000 A 200 A CT Rated Primary Current I8
633 IN-SEC CT I8 P.System Data 1 1A
5A
0.1A
1A CT Rated Secondary Current I8
641 STRPNT->BUS I9 P.System Data 1 YES
NO
YES CT-Starpoint I9 in Direction of
Busbar
642 IN-PRI CT I9 P.System Data 1 1 .. 100000 A 200 A CT Rated Primary Current I9
643 IN-SEC CT I9 P.System Data 1 1A
5A
0.1A
1A CT Rated Secondary Current I9
651 STRPNT->BUS I10 P.System Data 1 YES
NO
YES CT-Starpoint I10 in Direction of
Busbar
652 IN-PRI CT I10 P.System Data 1 1 .. 100000 A 200 A CT Rated Primary Current I10
653 IN-SEC CT I10 P.System Data 1 1A
5A
0.1A
1A CT Rated Secondary Current I10
661 STRPNT->BUS I11 P.System Data 1 YES
NO
YES CT-Starpoint I11 in Direction of
Busbar
662 IN-PRI CT I11 P.System Data 1 1 .. 100000 A 200 A CT Rated Primary Current I11
663 IN-SEC CT I11 P.System Data 1 1A
5A
0.1A
1A CT Rated Secondary Current I11
671 STRPNT->BUS I12 P.System Data 1 YES
NO
YES CT-Starpoint I12 in Direction of
Busbar
672 IN-PRI CT I12 P.System Data 1 1 .. 100000 A 200 A CT Rated Primary Current I12
673 IN-SEC CT I12 P.System Data 1 1A
5A
0.1A
1A CT Rated Secondary Current I12
711 EARTH IX1 AT P.System Data 1 Terminal Q7
Terminal Q8
Terminal Q7 Earthing electrod IX1 connected
to
712 IN-PRI CT IX1 P.System Data 1 1 .. 100000 A 200 A CT rated primary current IX1
713 IN-SEC CT IX1 P.System Data 1 1A
5A
1A CT rated secondary current IX1
721 EARTH IX2 AT P.System Data 1 Terminal N7
Terminal N8
Terminal N7 Earthing electrod IX2 connected
to
722 IN-PRI CT IX2 P.System Data 1 1 .. 100000 A 200 A CT rated primary current IX2
Addr. Parameter Function C Setting Options Default Setting Comments
