A.8 Settings
563
7UT613/63x Manual
C53000-G1176-C160-2
1111 PoleOpenCurr.S1 P.System Data 2 0.04 .. 1.00 I/InS 0.10 I/InS Pole Open Current Threshold
Side 1
1112 PoleOpenCurr.S2 P.System Data 2 0.04 .. 1.00 I/InS 0.10 I/InS Pole Open Current Threshold
Side 2
1113 PoleOpenCurr.S3 P.System Data 2 0.04 .. 1.00 I/InS 0.16 I/InS Pole Open Current Threshold
Side 3
1114 PoleOpenCurr.S4 P.System Data 2 0.04 .. 1.00 I/InS 0.16 I/InS Pole Open Current Threshold
Side 4
1115 PoleOpenCurr.S5 P.System Data 2 0.04 .. 1.00 I/InS 0.16 I/InS Pole Open Current Threshold
Side 5
1121 PoleOpenCurr.M1 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
Meas.Loc. M1
5A 0.20 .. 5.00 A 0.20 A
1122 PoleOpenCurr.M2 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
Meas.Loc. M2
5A 0.20 .. 5.00 A 0.20 A
1123 PoleOpenCurr.M3 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
Meas.Loc. M3
5A 0.20 .. 5.00 A 0.20 A
1124 PoleOpenCurr.M4 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
Meas.Loc. M4
5A 0.20 .. 5.00 A 0.20 A
1125 PoleOpenCurr.M5 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
Meas.Loc. M5
5A 0.20 .. 5.00 A 0.20 A
1131 PoleOpenCurr I1 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
End 1
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1132 PoleOpenCurr I2 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
End 2
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1133 PoleOpenCurr I3 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
End 3
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1134 PoleOpenCurr I4 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
End 4
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1135 PoleOpenCurr I5 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
End 5
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1136 PoleOpenCurr I6 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
End 6
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1137 PoleOpenCurr I7 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
End 7
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1138 PoleOpenCurr I8 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
End 8
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1139 PoleOpenCurr I9 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
End 9
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1140 PoleOpenCurrI10 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
End 10
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1141 PoleOpenCurrI11 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
End 11
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
1142 PoleOpenCurrI12 P.System Data 2 1A 0.04 .. 1.00 A 0.04 A Pole Open Current Threshold
End 12
5A 0.20 .. 5.00 A 0.20 A
0.1A 0.004 .. 0.100 A 0.004 A
